The Ebm-papst 4414 HHR is a 24V DC axial cooling fan designed for industrial and electronic applications. The fan, part of the Ebm-papst 4400 series, is known for efficient airflow and effective heat dissipation

The input 4650n-465 refers to the EBM-PAPST 4650N-465, an AC axial fan used for cooling and thermal management in a wide range of devices. Product specificationsAccording to the manufacturer and retailers like TME and DigiKey, here are the detailed specifications for the EBM-PAPST 4650N-465 fan
Common applicationsThe EBM-PAPST 4650N-465 fan is built for applications that need high airflow with low resistance, including:

• Refrigerated display cases
• Cold storage evaporators
• Heat pumps
• Air conditioners
• Industrial ovens
• Telecommunications equipment
• Automation machinery
• Elevator system

The product number A2E250-AM06-10 is not a standard product number for an ebm-papst fan. The correct part number is likely A2E250-AM06-01, with the -01 suffix indicating the standard model. The -10 suffix may specify a custom variant with different lead lengths, wires, or housing.

Common applicationsThe A2E250-AM06-01 is suitable for a wide range of applications that require high airflow, including:

• Heat pumps and air conditioners
• Refrigerated display cases and cold storage
• Inverter cooling
• Tabletop condensers
• Greenhouses

The product number K2E200-AH20-06 refers to an AC axial cooling fan manufactured by ebm-papst. It is a component designed for industrial and cabinet cooling applications.

Specifications

• Manufacturer: ebm-papst
• Part Number: K2E200-AH20-06
• Voltage: 230V AC
• Frequency: 50/60Hz
• Current Draw: 0.37/0.39 A
• Power: 70/87 W
• Application: Often used for cooling in equipment and electrical cabinets.
• Related models: The K2E200-AH20-06 is closely related to the K2E200-AH20-05, which is also a 230V ebm-papst fan

The part number 8414 NGH 24VDC refers to a high-performance DC axial fan manufactured by ebm-papst. It is part of the 8400N series and is widely used for thermal management in applications such as industrial electronics and telecommunications equipment
Common applications

• Electronics cooling: Provides reliable airflow for cooling critical electronic components in industrial equipment.
• Telecommunications: Manages heat in telecommunications infrastructure where compact and efficient cooling is essential.
• HVAC systems: Used in smaller ventilation and heating, ventilation, and air conditioning systems.
• Power supplies: Ensures efficient thermal management within power supply units to prevent overheating

The w2s130-aa03-01 is an ebm-papst W2S130 Series AC axial fan that operates on 230 V AC and features a durable metal construction. It is primarily used for industrial cooling applications
Common applicationsThe fan's features and robust construction make it well-suited for industrial equipment cooling. Examples of suitable applications include:

• Heat pumps
• Portable and split-system air conditioners
• Refrigerated display cases and cold storage evaporators
• Tabletop condensers

The G2D120-AA08-24 is a snail-type centrifugal fan unit from the manufacturer ebm-papst. It is designed for cooling and ventilation applications.
Technical specifications Based on information from electronics component distributors, here are the key features of the fan: Manufacturer: ebm-papst

• Type: Snail cooling fan unit / Centrifugal fan
• Voltage rating: 380/460V AC
• Frequency: 50/60Hz
• Current rating: 0.5A
• Power: 0.32 kW
• Speed: 2300 min-1to the negative 1 power−1 (revolutions per minute)
• Included components: The unit comes complete with a chassis, connection base, and a protective grille.

The ebm-papst W2D160-EB22-12 is an AC axial fan designed for industrial cooling applications, such as for use with Siemens inverter systems and CNC machines. It operates at either 400V or 480V AC, depending on the frequency. Specifications

• Manufacturer: ebm-papst
• Model number: W2D160-EB22-12
• Motor type: M2D068-BC
• Voltage: 400 VAC at 50 Hz, or 480 VAC at 60 Hz
• Current draw: 0.15 A (at 400 VAC, 50 Hz), 0.16 A (at 480 VAC, 60 Hz)
• Power input: 44 W (at 400 VAC, 50 Hz), 58 W (at 480 VAC, 60 Hz)
• Speed: 2800 RPM (at 400 VAC, 50 Hz), 3350 RPM (at 480 VAC, 60 Hz)
• Airflow:
  • 102.02 CFM (per IndiaMART)
  • 905 m³/h (per IndiaMART)
• Construction: Robust sheet steel and die-cast aluminum housing
• Dimensions: 172 x 172 x 51 mm (per IndiaMART)
• Minimum ambient temperature: -25°C

Key features

• High performance: The fan is engineered for high-performance cooling in demanding industrial environments.
• Energy efficient: It has a relatively low power consumption of 44W (at 400V).
• Durable construction: The fan is built to be long-lasting in various industrial settings.
• Compatible devices: It is compatible with Siemens servo motors and inverters

The part number W2E143-AB09-06 refers to a 172mm AC axial cooling fan manufactured by ebm-papst. It features a robust design with a die-cast aluminum housing and is suitable for high airflow industrial applications, including heat pumps and refrigerated display cases. Product specificationsAccording to product listings from suppliers like Industrybuying, Element14, and Newark Electronics, here are the specifications for the ebm-papst W2E143-AB09-06 fan:

• Manufacturer: ebm-papst
• Dimensions: 172mm (frame size) x 51mm (external depth)
• Voltage: 230V AC
• Power consumption: 24/30 watts
• Airflow: 294.2 CFM (Cubic Feet per Minute)
• Rotation: Counter-clockwise, viewed from the rotor
• Motor: External rotor shaded-pole motor
• Bearing: Ball bearing
• Connection: 2-pin terminal

The G2E160-AY47-01 is an ebm-papst AC centrifugal blower with a forward-curved, single-inlet design. It is typically used in applications requiring high airflow, such as HVAC systems and industrial ventilation. Specifications

• Manufacturer: ebm-papst
• Part number: G2E160-AY47-01
• Series: G2E160
• Fan type: Centrifugal blower with a single inlet and forward-curved blades
• Motor type: AC external rotor motor, 1-phase
• Dimensions: Approximately 227 x 130 x 262 mm, with a 160 mm impeller diameter
• Voltage: 230 VAC
• Frequency: 50/60 Hz
• Power consumption: 280 W (according to DigiKey and Mouser) or 240 W (according to TME and IndiaMART)
• Air flow: 600 m³/h or 347 CFM
• Speed: 2100 RPM
• Bearings: Ball bearings
• Housing material: Die-cast aluminum
• Impeller material: Galvanized sheet steel
• Ingress Protection (IP) rating: IP44, dependent on installation
• Features: Thermal Overload Protection (TOP)
• Operating temperature: -25 to 50 °C (or -13 to 86 °F)

Key Specifications

• Type: AC, backward‑curved centrifugal fan, single‑inlet (motorized impeller)

• Diameter: ~180 mm, depth ~78–85 mm

• Voltage & Frequency: 230 VAC, 50 Hz (100 W @ 60 Hz)

• Current: ~0.36 A (50 Hz), ~0.45 A (60 Hz)

• Power Draw: ~82 W @ 50 Hz and ~100 W @ 60 Hz

• Speed: ~2,300 RPM

• Bearings: Ball bearing with thermal-overload protector wired internally

• Airflow:

  • ~555 m³/h free-air (≈325 CFM) @ 50 Hz

  • ~335 CFM (~9.5 m³/min) typical Max Static Pressure: Up to ~310 Pa @ 50 Hz, ~390–400 Pa @ 60 Hz

• Noise: Approx. 63 dBA (as per Newark listing)

• Ambient Range: –25 °C to +40 °C (operational), –40 °C to +80 °C storage

• Ingress Protection: IP44 (with proper installation)

• Insulation Class: B; humidity class F1–2

• Weight: ~1.37 kg

• Certifications: CE, CCC, EAC

🧰 Use Cases

Designed for HVAC, industrial cooling, and applications needing higher pressure at moderate flow, the R2E180‑AS77‑05 is reliable and efficient, thanks to its thermal-overload protection and durable ball bearings

The code R2E190A026-05#EBM identifies an AC centrifugal fan made by the manufacturer ebm-papst. Here is a breakdown of the key specifications associated with this model:

• Brand: ebm-papst.
• Type: AC centrifugal fan with backward curved, single-inlet impeller blades.
• Diameter: 190 mm.
• Power: Powered by 230VAC and consumes 58 watts (at 50 Hz) or 75 watts (at 60 Hz).
• Airflow: Delivers an airflow of 570 cubic meters per hour (at 50 Hz).
• Speed: Operates at a speed of 2500 revolutions per minute (RPM).
• Bearings: It uses a ball bearing system.
• Features: The fan blades are resistant to dust and dirt and have high hydraulic efficiency.

This fan is designed for industrial applications requiring cooling and air circulation.
